Viqua Sterilight S5Q-P/12VDC Specialty UV System 5 GPM 1/2" MNPT

SKU:
S5Q-P/12VDC
Condition:
New
Weight:
8.00 LBS
Shipping:
Calculated at Checkout
462.78USD

Description

PRODUCT DOCUMENTATION

Viqua S5Q-P/12VDC is a compact POU (point of use) UV disinfection system designed for up to 5 gpm (8 lpm) flow rate. 12 Volt DC UV System is ideal choice for off grid applications.

FEATURES & BENEFITS

  • Designed to destroy Bacteria, Viruses and inactivate chlorine-resistant parasites such as Cryptosporidium and Giardia
  • Stainless steel chamber to prolong UV intensity and eliminate ultraviolet light degradation
  • Easy to maintain and service
  • UV lamp can be changed without interrupting the water flow

SPECIFICATION

  • Part Number: S25-P/12VDC
  • Desinfection Flow Rate: 30 mJ/cm2 @ 5.0 gpm
  • Desinfection Flow Rate: 40 mJ/cm2 @ 4.0 gpm
  • The UV Lamp Life: 9000 hours of continuous purification
  • Connection Size: 1/2" MNPT
  • Power Consumption: 26W
  • Voltage: 100-240V/50/60 Hz
  • Maximum Operating Pressure: 125 PSI

REPLACEMENT PARTS

  • Replacement UV Lamp: S463RL
  • Replacement UV Sleeve: QS-463
  • Replacement Lamp & Combo Kit: S463-QL
  • Replacement Power Supply: BA-RO/P/12
  • Replacement O-Ring: 410867
  • Retaining Nut: RN-001

WATER QUALITY REQUIREMENTS PRIOR TO UV TREATMENT

  • Iron < 0.3 ppm (0.3 mg/L)
  • Manganese < 0.05 ppm (0.05 mg/L)
  • Hardness < 7gpg
  • Tannins < 0.1 ppm (0.1 mg/L)
  • Turbidity < 1NTU UV transmittance > 75%
View AllClose

Warranty Information

One-Year Limited Warranty for Lamps, Sleeves and UV Sensors VIQUA warrants lamps, sleeves and UV sensors to be free from defects in material and workmanship for a period of one (1) year from the date of purchase. During this time, VIQUA will repair or replace, at its option, any defective parts covered by the warranty.Your dealer will process your claim and advise whether the defective item needs to be returned for failure analysis. IMPORTANT NOTE: Use only genuine Sterilight® replacement lamps and sleeves in your system. Failure to do so may seriously compromise disinfection performance and affect warranty coverage. General Conditions and Limitations None of the above warranties cover damage caused by improper use or maintenance, accidents, acts of God or minor scratches or imperfections that do not materially impair the operation of the product. The warranties also do not cover products that are not installed as outlined in the applicable Owner’s Manual. Parts repaired or replaced under these warranties will be covered under warranty up to the end of the warranty period applicable to the original part. The above warranties do not include the cost of shipping and handling of returned items The limited warranties described above are the only warranties applicable to the Sterilight® range of products. These limited warranties outline the exclusive remedy for all claims based on a failure of or defect in any of these products, whether the claim is based on contract, tort (including negligence), strict liability or otherwise. These warranties are in lieu of all other warranties whether written, oral, implied or statutory. Without limitation, no warranty of merchantability or of fitness for a particular purpose shall apply to any of these products. VIQUA does not assume any liability for personal injury or property damage caused by the use or misuse of any of the above products. VIQUA shall not in any event be liable for special, incidental, indirect or consequential damages. VIQUA’s liability shall, in all instances, be limited to repair or replacement of the defective product or part and this liability will terminate upon expiration of the applicable warranty period.
