Viqua 650647 UVMax PRO10 Professional Plus UV System 10 GPM 1.25" MNPT with UV Sensor NSF 55 Class A Certified

PRODUCT DOCUMENTATION

• VIQUA Home and Tap UV Brochure
• VIQUA UVMax PRO10 Manual
• VIQUA Light-Wise Technology
• Well Owner's Guide

Viqua UVMax PRO10 NSF 55 Class A Certified Disinfection UV System with Flow Meter, UV Sensor and Cool-Touch Fan Technology. Validated for up to 10 gpm (38 lpm) flow rate. Suitable for use in public applications.

FEATURES & BENEFITS

• Designed to destroy Bacteria, Viruses and inactivate chlorine-resistant parasites such as Cryptosporidium and Giardia
• Stainless steel chamber to prolong UV intensity and eliminate ultraviolet light degradation
• Easy to maintain and service
• The power supply controller visually displays the remaining lamp life and provides real-time UV dose
• UV lamp can be changed without interrupting the water flow
• Indicator lights show the status of system components. Warning lights appear when system maintenance is required
• The special lamp plug ensures that no one can power the UV lamp if it’s not in the UV chamber
• UV Sensor provides continuous feedback of UV system performance

SPECIFICATION

• Part Number:650647
• Model Number: PRO10
• Disinfection Flow Rate: 40 mJ/cm2 @10 gpm (38 lpm)
• The UV Lamp Life: 9000 hours of continuous purification
• Connection Size: 1.25" FNPT
• Power Consumption: 120W
• Voltage: 100-240V/50/60 Hz
• Maximum Operating Pressure: 125 PS

REPLACEMENT PARTS

• Replacement UV Lamp: 602854
• Replacement UV Sleeve: 602974
• Replacement Lamp & Combo Kit: 602850-101
• Replacement Power Supply: 650709-003
• UV Sensor: 650580

 WATER QUALITY REQUIREMENTS PRIOR TO THE UV TREATMENT

• Iron < 0.3 ppm (0.3 mg/L)
• Manganese < 0.05 ppm (0.05 mg/L)
• Hardness < 7gpg
• Tannins < 0.1 ppm (0.1 mg/L)
• Turbidity < 1NTU UV transmittance > 75%
