AquaLock Reducing Branch Tees

SKU:
3524R-1004
Condition:
New
Weight:
0.30 LBS
Shipping:
Calculated at Checkout

Bulk discount rates

Below are the available bulk discount rates for each individual item when you purchase a certain amount

Buy 5 - 10 and get 0.80CAD off
Buy 11 or above and get 1.50CAD off
  • AquaLock Reducing Branch Tees
  • AquaLock Reducing Branch Tees
19.60CAD

Description

Product Documentation:
Specification Sheet
Warranty

 AquaLock™ plastic reducing tee works with copper, CPVC, PEX, and CTS rated pipe. It is easy to install, no tools or tube inserts are required. The fitting can be used for hot and cold water applications. The unique O-ring guide feature provides a zero-leak connection. Unlike barb fittings, this fitting joins the tubing on the outside, increasing the flow capacity. After a connection has been made even under maximum pressure, the tubing is able to swivel, making the fitting ideal for vibrating and dynamic applications.

  • No tools required for installation or removal
  • Rotates under pressure after installed for high flexibility during installation
  • Can be used for hot and cold water applications, including behind the wall applications
  • Works with copper, CPVC, PEX, and CTS rated pipe
  • Zero-leak connections
  • 25-year limited warranty
Specifications
Brand Watts
Buy American Act Compliant NO
EAN 098268299465
Finish Plastic
Inlet Connection Size 1/2", 3/4", 1"
Inlet Connection Type Push to connect
Inlet Material Polysulfone
Lead Free YES
Material Polysulfone
Maximum Working Pressure-BAR 17.25
Maximum Working Pressure-PSI 250
Maximum Working Temperature-Celsius 24.00
Maximum Working Temperature-Fahrenheit 75
Minimum Temperature - Celsius 0.56
Minimum Temperature-Fahrenheit 33
Outlet Connection Size 1/4", 1/2", 3/4"
Outlet Connection Type Push to connect
Outlet Material Polysulfone
Outlet Thread Type Does Not Apply To Product
Part Number 0959095
Series Reducing Tee 3524R
Suitable for Gas Service No
